Dilong M30A Series 6.6kW OBC Liquid Cooled EV On Board Charger

Dilong M30A Series 6.6kW OBC Liquid Cooled EV On Board Charger

Model
DA6K6M30A
Input Voltage
220VAC(85-264VAC)
Output Voltage/Output Power
50VDC(30-55VDC)/3.8kW
70VDC(50-90VDC)/6.2kW
90VDC(70-132VDC)/6.6kW
150VDC(100-200VDC)/6.6kW
210VDC(160-300VDC)/6kW
360VDC(210-420VDC)/6.6kW
400VDC(300-550VDC)/6.6kW
600VDC(400-750VDC)/6.6kW
Quantity
Only 1000 left
Volume Pricing
Quantity
Price
1+
$1.00 USD each
Free worldwide shipping
Free returns
Carbon neutral
Secure payments

Description

PS:

The final price is subject to the actual quotation, click above to request a quote!(Any questions please contact dilong@dilongkeji.com)

1. DA6K6M30E is an OBC switching power converter. The charger adopts advanced all-digital resonant frequency modulation technology, which has high efficiency, high power, small size and reliable operation.

2. The charging mode adopts constant power,constant voltage and constant current automatic state transition, which effectively saves charging time.

3. With active power factor correction, zero pollution to the grid, wide input and output voltage range, using CAN2.0B communication protocol.

4. With intelligent charging function, it has intelligent monitoring fault alarm protection function,programme function and fault inquiry function;

5. it also has built-in 12V independent auxiliary power supply for power supply of car battery management system.

6. This power supply is specially designed for charging high-voltage batteries of new energy vehicles. which is completely synchronized with the world-class automobile power supply manufacturers.

7. The performance indicators have reached or exceeded the international peer level, and the fault-free running time is longer.

8. Wide input voltage range AC85V-AC264V 45Hz-65Hz available for worldwide requirements.

9. Up to 95% power efficiency and more than 94% Full Load Efficiency.

10. Fully-sealed and water-proof, protection class IP67(Effective against dust tight and Protection against Immersion, up to 1 m depth).

11. Operating temperature:- 40℃~80℃; Storage temperature:- 45℃~85℃; Mechanical impact and vibration grade: QC/t 895-2011, Automotive-grade seismic rating.

12. Multi-safety protection functions: Input over/under voltage and reverse polarity protection; Output over current/short circuit and over temp protection.

13. With active power factor correction function, power factor ≥ 0.99, right Low pollution of power grid.

Model Type of Cooling AC Input Voltage Input Voltage Range DC Output Voltage Output Voltage Range Rated Output Power
DA6K6M30A-50C Liquid Cooling 220Vac 85-264Vac 50Vdc 30-55Vdc 3800W
DA6K6M30A-70C Liquid Cooling 220Vac 85-264Vac 70Vdc 50-90Vdc 6200W
DA6K6M30A-90C Liquid Cooling 220Vac 85-264Vac 90Vdc 70-132Vdc 6600W
DA6K6M30A-150C Liquid Cooling 220Vac 85-264Vac 150Vdc 100-200Vdc 6600W
DA6K6M30A-210C Liquid Cooling 220Vac 85-264Vac 210Vdc 160-300Vdc 6000W
DA6K6M30A-360C Liquid Cooling 220Vac 85-264Vac 360Vdc 210-420Vdc 6600W
DA6K6M30A-400C Liquid Cooling 220Vac 85-264Vac 400Vdc 300-550Vdc 6600W
DA6K6M30A-600C Liquid Cooling 220Vac 85-264Vac 600Vdc 400-750Vdc 6600W
